FLUIDMASTER IN-WALL CISTERNS & WC FRAMES

Find a Store

Fluidmaster UP187 6/3l Dual Flush Front/Top Concealed Cistern

The Fluidmaster 187 concealed cistern offers an innovative solution for smaller spaces. The design allows fitting of the frame under windows or key bathroom features, whilst retaining full usability and operation.

The range of attractive plates can be mounted on the front or on top of the cistern providing ultimate flexibility for installation.

The 187 cistern features the silent Fluidmaster 747 valve; designed for ultra-simple maintenance and long-lasting performance.

Product Features
Technical Information
  • Dual flush 6/3 litre concealed cistern
  • Silent operation - Only The Best Inside Fluidmaster 747 fill valve
  • Attractive range of flushing plates designed for front or top mounted application
  • System fully insulated with polystyrene for long-lastingperformance
  • Can be installed with top mounted activation plate
  • 1/2" water connection
  • Adjutable water volumes
  • WRAS approved
  • Order Number

    UP187

  • Warranties and certifications
    10 years warranty, 25 years parts availability, CE, WRAS
  • Application
    WC
  • Material
    Plastic
  • Height
    360 mm
  • Width
    364 mm
  • Depth
    142 mm
  • Cistern Model
    187
  • Cistern Material
    Plastic
  • Mains Water Connection
    External thread
  • Size of mains water threaded connection (inch)
    1/2"
  • Minimum flushing water quantity
    3 Litres
  • Maximum flushing water quantity
    6 Litres
  • Adjustable water volumes
    YES
  • Mechanical activation plate compatible
    YES
  • Pneumatic activation plate compatible
    NO
  • Touchless/IR activation plate compatible
    NO
  • Front activation
    YES
  • Top activation
    YES
  • With shut-off valve
    YES
  • Pre-assembled
    YES
  • WRAS / KIWA certified
    WRAS
